SED200 Slim Frame Pocket Sliding Door With Honeycomb Aluminum Panels

SED200 Slim Frame Pocket Sliding Door offers a spacious view for natural light, a hidden frame design for a modern aesthetic, and a panel-mounted roller structure for improved stability and longevity. Additionally, a built-in insect screen allows ventilation while keeping pests out, and the lightweight honeycomb aluminum panels provide excellent insulation and soundproofing, enhancing comfort and functionality.

Material: Aluminum frame+hardware+glass
Applications: Office Buildings, Retail Spaces, Healthcare Facilities, Hotels And Tourist Places

For customization please contact our team!
  • SED200

  • TOPBRIGHT

Availability:
Quantity:

Why Choose SED200 Slim Frame Pocket Sliding Door With Honeycomb Aluminum Panels?


1. Spacious View

Explanation: The 3.6CM visible surface design allows for a larger glass area, providing an expansive view. Users can enjoy ample natural light and outdoor scenery, making it ideal for sunrooms, living rooms, or any space that benefits from light and visual connection.


Slim_Frame_Pocket_Sliding_Door_With_Honeycomb_Aluminum Panels_topbright(9)


2. Hidden Frame Design

The hidden frame design makes the door frame nearly invisible when closed, enhancing the overall aesthetic appeal. This reduces visual clutter, making the space appear cleaner and more modern, and it fits well with various interior decor styles.


Slim_Frame_Pocket_Sliding_Door_With_Honeycomb_Aluminum Panels_topbright(7)


3. Panel-Mounted Roller Structure

The panel-mounted roller design offers better load-bearing capacity and stability, ensuring smoother operation when opening and closing the door. Compared to traditional rollers, this design minimizes wear and extends the lifespan of the door, making it suitable for high-frequency usage.


Slim_Frame_Pocket_Sliding_Door_With_Honeycomb_Aluminum Panels_topbright(10)


4. Built-In Insect Screen

The integrated insect screen effectively blocks insects and dust while allowing for ventilation. Users can enjoy fresh air while keeping unwanted pests out, enhancing comfort and usability, especially during warmer months.


5. Honeycomb Aluminum Panels for Insulation

Honeycomb aluminum panels, used as embedded door frame materials, offer advantages such as lightweight, high strength, and excellent thermal insulation and soundproofing properties. These features significantly reduce installation burdens and enhance stability.


Slim_Frame_Pocket_Sliding_Door_With_Honeycomb_Aluminum Panels_topbright(5)

                                                                                 SED200 DETAIL
Roller SystemPanel-Mounted Sliding Door Roller
Hook Up Options36mm / 20mm
Handle Options

No Handle / One Side / Both Side

Closure Options

Yes

Hidden FrameYes
Hidden TrackNo
Maximum Door Panel Height5.5m
Maximum Door Panel Width

3m

Maximum Door Panel Weight

600kg
Maximum Area Of The Movable Panel11
Maximum Area Of The Fixed Panel16

Electric Opening

Yes
Smart LocksYes
Welcome LightYes
Glass Thickness

36mm



                                                                             SED200 ProMax DETAIL
Roller System

Frame-Mounted Sliding Door Roller

Hook Up Options20mm
Handle Options

One Side / Both Side

Closure Options

Yes

Hidden FrameYes
Hidden Track

Yes

Maximum Door Panel Height

6.5m

Maximum Door Panel Width

4m

Maximum Door Panel Weight

1.2T
Maximum Area Of The Movable Panel18
Maximum Area Of The Fixed Panel23

Electric Opening

Yes
Smart LocksYes
Welcome LightYes
Glass Thickness

36mm



                                              SED200 Slimline Lift Sliding Door DETAIL
Roller System

Panel-Mounted Sliding Door Roller

Hook Up Options20mm
Handle Options

No

Closure Options

No

Hidden FrameYes
Hidden Track

No

Maximum Door Panel Height

6.5m

Maximum Door Panel Width

4m

Maximum Door Panel Weight

600kg
Maximum Area Of The Movable Panel8
Maximum Area Of The Fixed Panel18

Electric Opening

No
Smart LocksNo
Welcome LightYes
Glass Thickness

36mm

Application Scenarios:

High-end residential spaces: With its sleek, modern design, this type of sliding door is perfect for high-end homes in areas like living rooms, bedrooms, or balconies. It helps divide spaces without compromising the overall sense of openness.


Commercial and office environments: The modern design with concealed tracks and narrow frames suits office buildings and meeting rooms, creating a professional and uncluttered atmosphere.


Hotels and resorts: These doors can be used in luxury hotel suites, recreational areas, or other upscale hospitality spaces, providing privacy while maintaining a sense of openness and modern design.


Villas and private luxury homes: Ideal for transition areas between indoor and outdoor spaces (such as gardens or patios), electric sliding doors elevate the overall aesthetic while providing functionality and a sense of luxury.

Electric sliding doors offer a balance of functionality and aesthetics, making them popular in premium settings.



SED200_Slim_Frame_Four-Track_Sliding_Door_TOPBRIGHT (2)    SED200_Slim_Frame_Four-Track_Sliding_Door_TOPBRIGHT (1)
